Screw Compressor APS 9 Basic G2 Combi Dry 10 bar 10 hp/7.5 kW 984 l/min 500 l
SKU
362959
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 362959 |
|---|---|
| EAN | 8712418400014 |
| Length (mm) | 1937 |
| Width (mm) | 665 |
| Height (mm) | 1500 |
| Weight (kg) | 296,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 10.0 HP / 7.5 kW |
| Motor efficiency class | IE3 |
| Motor Type | AC |
| Drive | V-belt driven |
| Control panel | ON/OFF |
| Dryer | Yes |
| Dryer voltage (V) | 230 |
| Air receiver | Yes |
| Capacity air receiver (l) | 500 |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
| Free air delivery (l/min) | 984 |
|---|---|
| Free air delivery (m3/h) | 59.04 |
| Noise level dB(A) (0 m) | 68 |
| Noise level dB(A) (4 m) | 48 |
| Cut-in pressure (bar) | 8 |
| Plug type | EU |
| Refrigerant | R513A |
| Cooling air volume (m3/h) | 756 |
| Main air connection (") | 1/2" - 3/4" |
| Oilfree | No |
| Oil capacity (l) | 3.20 |
| Air-end | C43 |
| Stages | 1 |
| Start | Y-∆ |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | No |
| Autoregulation of idling | Yes |
