Screw Compressor APS 7.5 IVR Combi Dry X 10 bar 7.5 hp/5.5 kW 170-760 l/min 200 l

APS 7.5 IVR Combi Dry energy, high quality of compressed air and reliability in industrial applications.
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
SKU | 369957-IVR |
---|---|
EAN | 8712418372335 |
Length (mm) | 1450 |
Width (mm) | 670 |
Height (mm) | 1474 |
Weight (kg) | 280,00 |
Workload (labor/rest %) | 100/0 |
Motor power (hp / kW) | 7.5 HP / 5.5 kW |
Motor efficiency class | IE3 |
Motor Type | PM |
Drive | Direct driven 1:1 |
Control panel | MAM-6080 |
Available languages | English, Dutch, Polish, German |
Dryer | Yes |
Dryer voltage (V) | 230 |
Air receiver | Yes |
Capacity air receiver (l) | 200 |
Galvanized tank | No |
Maximum pressure (bar) | 10 |
Cut-in pressure (bar) | 6 |
Free air delivery at 8 bar (l/min) | 760 |
Free air delivery at 10 bar (l/min) | 690 |
Minimum free air delivery (l/min) | 170 |
---|---|
Minimum free air delivery (m3/h) | 10.2 |
Maximum free air delivery (l/min) | 760 |
Maximum free air delivery (m3/h) | 45.6 |
Noise level dB(A) (0 m) | 63 |
Noise level dB(A) (4 m) | 43 |
Plug type | EU |
Cooling air volume (m3/h) | 2300 |
Main air connection (") | 3/4 |
Minimum ambient temperature (°C) | 10 |
Maximum ambient temperature (°C) | 45 |
Oilfree | No |
Oil capacity (l) | 6 |
Stages | 1 |
Start | Inverter |
Voltage (V) | 400 V / 50 Hz / 3 Ph |
IP classification | IP55 |
Variable speed (IVR) | Yes |
Minimum rpm 10 bar (rpm) | 1100 |
Maximum rpm 10 bar (rpm/Hz) | 1960 |
Minimum energy consumption 10 bar (kW/m3/h) | 9.4 |
Maximum energy consumption 10 bar (kW/m3/h) | 10.8 |
Recommended
Description
APS 7.5 IVR Combi Dry X screw compressor 10 bar 7.5 HP/5.5 kW 170-760 l/min 200 l
APS 7.5 IVR Combi Dry X is a modern screw compressor designed for demanding industrial environments. The device with a power of 7.5 HP (5.5 kW) generates air flow ranging from 170 to 760 l/min at a maximum pressure of 10 bar. Thanks to the built-in refrigerant dryer and a tank with a capacity of 200 l, the compressor ensures high quality of compressed air, eliminating moisture and stabilizing the pressure in the system.
The most important advantages of APS 7.5 IVR Combi Dry X:
- Built-in refrigerant dryer – Removes moisture from the compressed air system, protecting pneumatic equipment and tools from corrosion and extending their life.
- Variable speed (IVR) technology – Dynamically adjusts the engine speed to current needs, reducing energy consumption by up to 40% compared to constant speed devices.
- 1:1 direct drive – Direct power transfer minimizes energy losses and increases the efficiency of the device.
- Compact 200 l tank – Allows for stable storage of compressed air, enabling continuous operation of the system even with variable demand.
Synchronous motor with permanent magnets (PM)
The APS 7.5 IVR Combi Dry X compressor uses a synchronous motor with permanent magnets, which is characterized by high energy efficiency and durability. Inverter control ensures precise adjustment of operating parameters to the current demand, which minimizes energy consumption and operating costs.
Advanced MAM-6080 controller
The device is equipped with a MAM-6080 microprocessor controller, which offers intuitive management of operating parameters. Features such as weekly programming, automatic restart and intelligent ventilation management allow you to optimize performance and reduce operating costs.
Energy efficiency and sustainability
APS 7.5 IVR Combi Dry X ensures energy savings and operational stability thanks to variable speed technology and a built-in dryer. Solid construction and the use of the highest quality components guarantee reliability and long service life of the device even in the most demanding industrial conditions.
Technical specifications:
- Operating pressure range: 6-10 bar
- Engine power: 7.5 HP / 5.5 kW
- Air flow: 170-760 l/min
- Tank capacity: 200 l
- Power supply: 400 V / 50 Hz / 3 phases
- Noise level: 63 dB(A)
APS 7.5 IVR Combi Dry X is an ideal solution for companies looking for a compact, energy-saving and reliable compressor. Its efficiency, modern technologies and high quality of compressed air make it perfect for a wide range of industrial applications.
