Screw compressor APS 7.5 Basic 10 bar 7.5 hp/5.5 kW 690 l/min
APS 7.5 Basic is an efficient screw compressor with a flow of 690 l/min and a pressure of 10 bar. Perfect for industrial and workshop applications requiring high quality compressed air.
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 364807 |
|---|---|
| EAN | 8712418347654 |
| Length (mm) | 620 |
| Width (mm) | 950 |
| Height (mm) | 605 |
| Weight (kg) | 160,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 7.5 HP / 5.5 kW |
| Motor efficiency class | IE3 |
| Motor Type | AC |
| Drive | V-belt driven |
| Control panel | ES 4000 BASIC |
| Dryer | No |
| Air receiver | No |
| Galvanized tank | No |
|---|---|
| Maximum pressure (bar) | 10 |
| Free air delivery (l/min) | 690 |
| Free air delivery (m3/h) | 41.4 |
| Noise level dB(A) (0 m) | 64 |
| Noise level dB(A) (4 m) | 44 |
| Plug type | EU |
| Main air connection (") | 3/4 |
| Oilfree | No |
| Air-end | C55* |
| Stages | 1 |
| Start | Y-∆ |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | No |
Recommended
Description
APS 7.5 Basic screw compressor 10 bar 7.5 HP/5.5 kW 690 l/min
APS 7.5 Basic is a reliable screw compressor designed for industrial and workshop applications that require stable and high air quality. It offers an air flow of 690 l/min at a maximum working pressure of 10 bar, making it an ideal choice for demanding applications.
Advanced design of the APS Basic series
The APS 7.5 Basic compressor combines solid workmanship with modern technological solutions, offering efficiency and durability. The screw module made of high-quality materials ensures reliability and stable operating parameters. Thanks to the low noise level of 66 dB(A), the device is perfect for places where work comfort is a priority. The compact design facilitates installation in limited spaces while maintaining full functionality.
- Belt drive: Stable power transmission minimizes energy losses and increases the service life of the device.
- IE3 motor: The energy-saving IE3 motor reduces energy consumption by up to 15%, lowering operating costs.
- Cooling system: Efficient air and oil coolers ensure optimal operating temperature, increasing the durability of components.
- ES 4000 Basic Controller: Intuitive control system allows easy monitoring of operating parameters and planning of maintenance.
Efficiency and air quality
APS 7.5 Basic offers a capacity of 690 l/min at an operating pressure of up to 10 bar, which allows for effective powering of pneumatic tools and industrial equipment. The device ensures constant operating parameters, eliminating the risk of interruptions and losses in production processes.
Technical specifications:
- Operating pressure range: up to 10 bar
- Engine power: 7.5 HP / 5.5 kW
- Air flow: 690 l/min
- Noise level: 66 dB(A)
Versatility and efficiency
APS 7.5 Basic is an ideal solution for medium-sized production plants and workshops where reliability and high quality of compressed air are required. The compact design and low noise level make the device an excellent choice for installation near workstations. Thanks to modern technologies, the compressor offers stable performance with minimal operating costs.
Investment in reliability
By choosing APS 7.5 Basic, you get a device that combines durability, efficiency and ease of use. The use of energy-saving solutions and solid construction guarantee long service life and stable operating parameters. It is a reliable choice for users looking for a high-class compressor for everyday use.
