Screw Compressor APS 60 IVR X 10 bar 60 hp/45 kW 2350-7200 l/min
APS 60 IVR l/min at a maximum pressure of 10 bar, ensuring energy savings and reliability in intense industrial environments.
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 369460-IVR |
|---|---|
| EAN | 8712418388275 |
| Length (mm) | 1470 |
| Width (mm) | 1000 |
| Height (mm) | 1370 |
| Weight (kg) | 620,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 60.0 HP / 45.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | PM |
| Drive | Direct driven 1:1 |
| Control panel | MAM-6080 |
| Available languages | English, Dutch, Polish, German |
| Dryer | No |
| Air receiver | No |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
| Cut-in pressure (bar) | 6 |
| Free air delivery at 8 bar (l/min) | 7200 |
| Free air delivery at 10 bar (l/min) | 6200 |
| Minimum free air delivery (l/min) | 2350 |
| Minimum free air delivery (m3/h) | 141 |
|---|---|
| Maximum free air delivery (l/min) | 7200 |
| Maximum free air delivery (m3/h) | 432 |
| Noise level dB(A) (0 m) | 80 |
| Noise level dB(A) (4 m) | 60 |
| Plug type | EU |
| Cooling air volume (m3/h) | 6800 |
| Main air connection (") | 1 1/2 |
| Minimum ambient temperature (°C) | 10 |
| Maximum ambient temperature (°C) | 45 |
| Oilfree | No |
| Oil capacity (l) | 18 |
| Stages | 1 |
| Start | Inverter |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| IP classification | IP55 |
| Variable speed (IVR) | Yes |
| Minimum rpm 10 bar (rpm) | 1180 |
| Maximum rpm 10 bar (rpm/Hz) | 3200 |
| Minimum energy consumption 10 bar (kW/m3/h) | 8.1 |
| Maximum energy consumption 10 bar (kW/m3/h) | 14.1 |
Recommended
Description
APS 60 IVR X 10 bar screw compressor 60 HP/45 kW 2350-7200 l/min
APS 60 IVR X is a technologically advanced screw compressor designed to work in the most demanding industrial environments. Thanks to the power of 60 HP (45 kW) and variable speed technology (IVR), the device offers air flow ranging from 2,350 to 7,200 l/min at a maximum pressure of 10 bar. High performance and energy efficiency make this model an ideal solution for companies that need a reliable source of compressed air.
The most important advantages of APS 60 IVR X:
- Variable speed operation system (IVR) – Adjusts the engine speed to the current demand for compressed air, saving up to 40% of energy compared to traditional fixed-speed compressors.
- High air efficiency – Flow range from 2,350 to 7,200 l/min supports a variety of industrial applications.
- 1:1 direct drive – Direct power transfer from the engine to the compression module eliminates energy losses, increasing work efficiency.
Synchronous motor with permanent magnets (PM)
Equipped with a modern synchronous motor with permanent magnets, APS 60 IVR X offers exceptional energy efficiency and durability. The inverter enables precise control of rotational speed, which reduces energy consumption and operating costs. Bearingless design reduces the need for maintenance and extends the life of the device.
Advanced MAM-6080 controller
The intuitive MAM-6080 controller allows full control over the compressor's operating parameters. Features such as automatic restart, weekly programming and intelligent cooling management guarantee optimized operation of the device with minimal operating costs.
Energy efficiency and sustainability
APS 60 IVR X is a compressor that combines high efficiency with energy saving. Thanks to variable speed technology and direct drive, it ensures low operating costs and long service life, meeting the expectations of the most demanding users.
Technical specifications:
- Operating pressure range: 6-10 bar
- Engine power: 60 HP / 45 kW
- Air flow: 2350-7200 l/min
- Power supply: 400 V / 50 Hz / 3 phases
- Noise level: 70 dB(A)
APS 60 IVR X is a reliable choice for companies looking for a powerful and energy-efficient solution for the most demanding industrial applications.
