Screw Compressor APS 50 IVR X 10 bar 50 hp/37 kW 1370-6200 l/min
The APS 50 IVR-X compressor from Airpress is 147 x 100 x 137 cm in size and weighs 610 kg. The compressor has a capacity of 50 hp and 37 kW. At 10 bar the compressor has a capacity of 5620 liters per minute, at 8 bar this is 6200 liters per minute. This machine is especially suitable for larger companies.
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 369450-IVR |
|---|---|
| EAN | 08712418372366 |
| Length (mm) | 1470 |
| Width (mm) | 1000 |
| Height (mm) | 1370 |
| Weight (kg) | 610,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 50.0 HP / 37.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | PM Synchroon Motor |
| Motor protection class | IP55 |
| Drive | Direct driven 1:1 |
| Control panel | MAM-6080 |
| Available languages | English, Dutch, Polish, German |
| Dryer | No |
| Air receiver | No |
| Capacity air receiver (l) | No |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
| Free air delivery at 8 bar (l/min) | 6200 |
| Free air delivery at 10 bar (l/min) | 5620 |
| Minimum free air delivery (l/min) | 1370 |
| Minimum free air delivery (m3/h) | 82.2 |
|---|---|
| Maximum free air delivery (l/min) | 6200 |
| Maximum free air delivery (m3/h) | 372 |
| Noise level dB(A) (0 m) | 80 |
| Noise level dB(A) (4 m) | 60 |
| Cut-in pressure (bar) | 6 |
| Plug type | EU |
| Cooling air volume (m3/h) | 6800 |
| Main air connection (") | 1 1/2 |
| Minimum ambient temperature (°C) | 10 |
| Maximum ambient temperature (°C) | 45 |
| Oilfree | No |
| Oil capacity (l) | 18 |
| Stages | 1 |
| Start | Inverter |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | Yes |
| Minimum rpm 10 bar (rpm) | 1000 |
| Maximum rpm 10 bar (rpm/Hz) | 2700 |
| Minimum energy consumption 10 bar (kW/m3/h) | 7.8 |
| Maximum energy consumption 10 bar (kW/m3/h) | 9.8 |
Recommended
Description
A compressor with great qualities and characteristics. This 37 kW is the largest compressor from the single-stage line that we offer. A directly coupled oversized screw block on a permanent magnet motor ensures maximum efficiency. Maximum yield even at low revs. The temperature controlled fan only runs when it is needed, so as long as the oil temperature is below the set value, it does not run and there is also no power consumption. This compressor can deliver up to 6200 liters per minute. The full color touch screen makes reading and adjusting very easy. All components are easily accessible when the panels are removed during maintenance. The machine has been carefully designed so that fewer parts are maintenance-sensitive. The service interval of 3,000 hours also ensures lower maintenance costs.
This machine is very suitable for large companies that, for example, radiate and therefore have a very varying decrease in compressed air.
X series Screw compressors
By continuously investing in the development of our products, the Airpress Group presents a new series of screw compressors. The screw compressors are available from 5.5 kW to 37 kW. The APS X series is available in two versions: controlled at a fixed speed or speed. Machines of 15 kW are also available with a two-stage screw block. These versions have an increased performance with the same power consumption as a single-stage version. Depending on demand, these machines are available as a separate unit, mounted on a tank or mounted on a tank and equipped with a compressed air dryer. Compressors of the X series are characterized by a new generation of screw blocks. The direct drive avoids losses due to the transmission. Reliable and efficient, easy-to-use screw compressors ensure trouble-free operation at minimal costs. Equipped with a modern control panel, you can constantly monitor the screw compressor and change parameters if necessary.
