Screw Compressor APS 5.5 Basic G2 10 bar 5.5 hp/4 kW 516 l/min
APS 5.5 Basic G2 is a compact screw compressor with a power of 5.5 HP (4 kW), maximum pressure of 10 bar and capacity of 516 l/min. Perfect for workshops and production plants, it offers reliability and energy savings.
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 362805 |
|---|---|
| EAN | 8712418399905 |
| Length (mm) | 620 |
| Width (mm) | 630 |
| Height (mm) | 950 |
| Weight (kg) | 120,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 5.5 HP / 4.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | AC |
| Drive | V-belt driven |
| Control panel | ON/OFF |
| Dryer | No |
| Air receiver | No |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
|---|---|
| Cut-in pressure (bar) | 8 |
| Free air delivery (l/min) | 516 |
| Free air delivery (m3/h) | 30.96 |
| Noise level dB(A) (0 m) | 62 |
| Noise level dB(A) (4 m) | 42 |
| Plug type | EU |
| Main air connection (") | 3/4 |
| Oilfree | No |
| Oil capacity (l) | 2.50 |
| Air-end | C43 |
| Stages | 1 |
| Start | Y-∆ |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | No |
Recommended
Description
APS 5.5 Basic G2 screw compressor 10 bar 5.5 HP/4 kW 516 l/min
APS 5.5 Basic G2 is an advanced screw compressor, designed for intensive use in workshops and small production plants. With a capacity of 516 l/min and a maximum working pressure of 10 bar, the device meets the requirements of a wide range of industrial applications.
Advanced design of the APS Basic series
The APS 5.5 Basic G2 compressor combines precision of workmanship with modern technological solutions, ensuring reliability and energy savings. The screw module made of high-quality materials guarantees long service life, and the solid construction of the housing allows noise attenuation to a level of 62 dB(A), which increases the comfort of work in its surroundings.
- Belt drive: Highly efficient power transmission system ensures stable operating parameters and reduces maintenance costs.
- IE3 motor: The energy-saving IE3 class motor reduces energy consumption by up to 15%, contributing to the optimization of operating costs.
- ON/OFF control panel: The intuitive control system allows you to easily manage the basic functions of the device.
- Cooling system: Air and oil coolers with independent fans maintain stable operating temperatures, ensuring reliability even in intensive cycles.
- Compact design: The small design allows the device to be installed in places with limited space.
Efficiency and air quality
APS 5.5 Basic G2 supplies compressed air with a capacity of 516 l/min, which makes it an ideal solution for powering pneumatic tools and production equipment. The advanced screw module minimizes energy loss, ensuring efficiency and reliability in everyday tasks.
Technical specifications:
- Operating pressure range: up to 10 bar
- Engine power: 5.5 HP / 4 kW
- Air flow: 516 l/min
- Type of drive: Belt
Versatility and efficiency
APS 5.5 Basic G2 is a device designed for users looking for reliable and effective screw compressors. Its energy-saving technological solutions and solid construction guarantee stable operation with minimal operating costs. Thanks to the low noise level, the compressor can be installed close to work stations, which increases the convenience of use.
Investment in reliability
By choosing APS 5.5 Basic G2, you are investing in a device that combines energy efficiency with a solid construction. It is an excellent choice for workshops and small industrial plants that require high quality compressed air while reducing operating costs.
