Screw Compressor APS 40 IVR X 10 bar 40 hp/30 kW 1050-4500 l/min

APS 40 IVR min at pressure up to 10 bar, guaranteeing energy savings, reliability and high efficiency. Perfect for demanding industrial applications.
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
SKU | 369440-IVR |
---|---|
EAN | 8712418372359 |
Length (mm) | 1300 |
Width (mm) | 950 |
Height (mm) | 1360 |
Weight (kg) | 550,00 |
Workload (labor/rest %) | 100/0 |
Motor power (hp / kW) | 40.0 HP / 30.0 kW |
Motor efficiency class | IE3 |
Motor Type | PM |
Drive | Direct driven 1:1 |
Control panel | MAM-6080 |
Available languages | English, Dutch, Polish, German |
Dryer | No |
Air receiver | No |
Galvanized tank | No |
Maximum pressure (bar) | 10 |
Cut-in pressure (bar) | 6 |
Free air delivery at 8 bar (l/min) | 4500 |
Free air delivery at 10 bar (l/min) | 4240 |
Minimum free air delivery (l/min) | 1050 |
Minimum free air delivery (m3/h) | 63 |
---|---|
Maximum free air delivery (l/min) | 4500 |
Maximum free air delivery (m3/h) | 270 |
Noise level dB(A) (0 m) | 70 |
Noise level dB(A) (4 m) | 50 |
Plug type | EU |
Cooling air volume (m3/h) | 8000 |
Main air connection (") | 1 1/4 |
Minimum ambient temperature (°C) | 10 |
Maximum ambient temperature (°C) | 45 |
Oilfree | No |
Oil capacity (l) | 15 |
Stages | 1 |
Start | Inverter |
Voltage (V) | 400 V / 50 Hz / 3 Ph |
IP classification | IP55 |
Variable speed (IVR) | Yes |
Minimum rpm 10 bar (rpm) | 820 |
Maximum rpm 10 bar (rpm/Hz) | 2200 |
Minimum energy consumption 10 bar (kW/m3/h) | 8.65 |
Maximum energy consumption 10 bar (kW/m3/h) | 12.6 |
Recommended
Description
APS 40 IVR X 10 bar screw compressor 40 HP/30 kW 1050-4500 l/min
APS 40 IVR X is a powerful and reliable screw compressor designed for intensive industrial applications. Thanks to the power of 40 HP (30 kW) and variable speed technology (IVR), the device offers air flow ranging from 1,050 to 4,500 l/min at a maximum pressure of 10 bar. This solution guarantees flexibility, energy efficiency and performance, meeting the requirements of the most demanding work environments.
The most important advantages of APS 40 IVR X:
- Variable speed work system (IVR) – IVR technology adjusts the engine speed to the current demand, which allows for energy savings of up to 40% compared to constant speed devices.
- High air efficiency – A flow range from 1050 to 4500 l/min makes this compressor ideal for a wide range of industrial applications.
- 1:1 direct drive – Direct power transfer from the engine to the compression module minimizes energy losses, increasing work efficiency.
Synchronous motor with permanent magnets (PM)
The APS 40 IVR X compressor is equipped with a synchronous motor with permanent magnets, which is characterized by high energy efficiency and exceptional durability. The inverter ensures precise adjustment of rotational speed to current demand, which reduces operating costs and the need for maintenance.
Advanced MAM-6080 controller
The MAM-6080 microprocessor controller allows full control over the compressor's operating parameters, providing functions such as automatic restart, weekly programming and intelligent cooling management. This intuitive solution allows you to optimize performance and minimize operating costs.
Energy efficiency and sustainability
APS 40 IVR X is a combination of advanced technology and reliability. Thanks to variable speed technology and direct drive, the device guarantees energy savings, low operating costs and long service life, meeting the expectations of the most demanding users.
Technical specifications:
- Operating pressure range: 6-10 bar
- Engine power: 40 HP / 30 kW
- Air flow: 1050-4500 l/min
- Power supply: 400 V / 50 Hz / 3 phases
- Noise level: 68 dB(A)
- Dimensions: 1300 x 880 x 1185 mm
- Weight: 550 kg
APS 40 IVR X is an excellent choice for companies looking for an efficient, reliable and energy-saving screw compressor. Its high efficiency and advanced technologies make it meet the requirements of the most demanding industrial environments.
