Screw Compressor APS 4 Basic G2 Combi 10 bar 4 hp/3 kW 366 l/min 200 l
Only 10 left
SKU
362904
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 362904 |
|---|---|
| EAN | 8712418399936 |
| Length (mm) | 1430 |
| Width (mm) | 600 |
| Height (mm) | 1260 |
| Weight (kg) | 170,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 4.0 HP / 3.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | AC |
| Drive | V-belt driven |
| Control panel | ON/OFF |
| Dryer | No |
| Air receiver | Yes |
| Capacity air receiver (l) | 200 |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
|---|---|
| Cut-in pressure (bar) | 8 |
| Free air delivery (l/min) | 366 |
| Free air delivery (m3/h) | 21.96 |
| Noise level dB(A) (0 m) | 61 |
| Noise level dB(A) (4 m) | 41 |
| Plug type | EU |
| Main air connection (") | 3/4 |
| Oilfree | No |
| Oil capacity (l) | 2.50 |
| Air-end | C43 |
| Stages | 1 |
| Start | Direct |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | No |
