Screw Compressor APS 35BD IVR Dry 13 bar 35 hp/26 kW 767-4835 l/min
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 36435-BDX-IVR |
|---|---|
| EAN | 8712418347289 |
| Length (mm) | 1320 |
| Width (mm) | 830 |
| Height (mm) | 1555 |
| Weight (kg) | 514,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 35.0 HP / 26.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | PM |
| Drive | Direct driven 1:1 |
| Control panel | ES 4000 STANDARD |
| Dryer | Yes |
| Dryer voltage (V) | 230 |
| Air receiver | No |
| Galvanized tank | No |
| Maximum pressure (bar) | 13 |
| Cut-in pressure (bar) | 5.5 |
| Minimum free air delivery (l/min) | 767 |
|---|---|
| Minimum free air delivery (m3/h) | 46.02 |
| Maximum free air delivery (l/min) | 4835 |
| Maximum free air delivery (m3/h) | 290.1 |
| Noise level dB(A) (0 m) | 68 |
| Noise level dB(A) (4 m) | 48 |
| Plug type | EU |
| Cooling air volume (m3/h) | 4800 |
| Main air connection (") | 1 |
| Oilfree | No |
| Air-end | C80 |
| Stages | 1 |
| Start | Inverter |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Power cable | 4 x 25 mm2 |
| Variable speed (IVR) | Yes |
| Minimum rpm 10 bar (rpm) | 5262 |
| Maximum rpm 10 bar (rpm/Hz) | 7768 |
Description
APS 35BD IVR Dry screw compressor 13 bar 35 HP/26 kW 770-4835 l/min
APS 35BD IVR Dry is an advanced variable-speed screw compressor with a built-in refrigerant dryer, designed for industrial plants with large and variable demand for compressed air. It offers performance in the range of 770–4835 l/min at a maximum working pressure of 13 bar, ensuring the highest air quality and energy savings.
Advanced design of the APS-BD IVR Dry series
The APS 35BD IVR Dry compressor combines modern technology with a solid construction, ensuring reliability, durability and energy efficiency. The built-in refrigerant dryer eliminates moisture from the air, ensuring quality class 1.4.1 according to the ISO 8573-1 standard, making the device an ideal choice for precision industrial applications.
- Direct drive 1:1: Direct connection of the engine with the compression module eliminates energy losses, increasing efficiency and stability of operating parameters. The drive design reduces the need for maintenance, which translates into lower operating costs.
- Inverter technology: The inverter dynamically adjusts the engine speed to current needs, reducing energy consumption by up to 30%. This solution allows for a significant reduction in operating costs and extension of component life.
- Integrated refrigeration dryer: Guarantees dry and clean air, eliminating moisture and protecting pneumatic installations against corrosion and damage.
- IE3 class motor: Energy-saving, durable and optimized for operation in difficult industrial conditions.
- ES 4000 Standard controller: Allows real-time monitoring of operating parameters, offering the ability to plan maintenance and quickly diagnose faults.
- Cooling system: Multi-stage cooling system includes high-efficiency air and oil coolers and independent fans, ensuring optimal operating temperature and continuous operation reliability.
Efficiency and air quality
The APS 35BD IVR Dry compressor offers impressive performance in the range of 770-4835 l/min at a maximum working pressure of 13 bar. The integrated dehumidifier provides the highest quality dry air, eliminating the need for external treatment systems and simplifying installation.
Technical specifications:
- Operating pressure range: up to 13 bar
- Engine power: 35 HP / 26 kW
- Air flow: 770–4835 l/min
- Drive type: Direct 1:1
- Dehumidifier: Integrated refrigerant dryer
- Controller: ES 4000 Standard
- Noise level: 68 dB(A)
Versatility and efficiency
APS 35BD IVR Dry has been designed for a wide range of industrial applications. Thanks to its compact design, low noise level and integrated dryer, the device works well in various work environments, ensuring comfort of use and high quality of compressed air.
Comprehensive support for the industry
Choosing the APS 35BD IVR Dry model is an investment in quality and reliability. Thanks to the use of advanced technologies and top-class components, the device meets the requirements of the most demanding users, offering efficiency, durability and energy savings.
