Screw Compressor APS 30BD IVR Dry 13 bar 30 hp/22 kW 766-4167 l/min
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 36430-BDX-IVR |
|---|---|
| EAN | 8712418359817 |
| Weight (kg) | 503 kg |
| Length (mm) | 1,320 mm1.32 m |
| Width (mm) | 830 mm8.3 dm |
| Height (mm) | 1,555 mm1.555 m |
| Drive | Direct driven 1:1 |
| Start | Inverter |
| Motor Type | PM |
| Motor power (hp / kW) | 30.0 HP / 22.0 kW |
| Motor efficiency class | IE3 |
| Air-end | C80 |
| Stages | 1 |
| Variable speed (IVR) | Yes |
| Minimum rpm 10 bar (rpm) | 5,262 rpm1.462 rpm/Hz |
| Maximum rpm 10 bar (rpm/Hz) | 7,768 rpm/Hz466.08 kHz |
| Control panel | ES 4000 STANDARD |
| Air receiver | No |
| Galvanized tank | No |
|---|---|
| Dryer | Yes |
| Dryer voltage (V) | 230 |
| Cooling air volume (m3/h) | 2,300 m³/h38.333 m³/min |
| Workload (labor/rest %) | 100/0 |
| Maximum pressure (bar) | 13 |
| Minimum working pressure (bar) | 5.5 bar |
| Minimum free air delivery (l/min) | 766 L/m1.277 L/h |
| Minimum free air delivery (m3/h) | 45.96 m³/h2.128 L/m |
| Maximum free air delivery (l/min) | 4,167 L/m6.945 L/h |
| Maximum free air delivery (m3/h) | 250.02 m³/h4.167 m³/min |
| Noise level dB(A) (0 m) | 68 |
| Noise level dB(A) (4 m) | 48 |
| Main air connection (") | 1 |
| Oilfree | No |
| Plug type | EU |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Power cable | 4 x 25 mm2 |
Recommended
Description
APS 30BD IVR Dry screw compressor 13 bar 30 HP/22 kW 770-4170 l/min
APS 30BD IVR Dry is a variable speed screw compressor with a built-in refrigerant dryer, designed for industrial plants with large but variable demand for compressed air. Thanks to inverter technology and 1:1 direct drive, the device offers efficiency from 770 to 4170 l/min at an operating pressure of up to 13 bar, ensuring the highest air quality and energy savings.
Advanced design of the APS-BD IVR Dry series
The APS 30BD IVR Dry compressor combines a solid construction with innovative technological solutions that ensure reliability, ease of use and energy savings. The built-in refrigerant dryer eliminates moisture from the air, providing compressed air with quality class 1.4.1 in accordance with the ISO 8573-1 standard.
- Direct drive 1:1: Direct transmission of power from the engine to the compression module eliminates energy losses, ensuring stable operating parameters and minimal operating costs.
- Inverter technology: Dynamic adjustment of the engine speed to the current demand for compressed air, which saves up to 30% of energy and reduces mechanical wear of components.
- Integrated refrigeration dryer: Provides the highest quality air, eliminating moisture and minimizing the risk of corrosion and damage to pneumatic machines.
- IE3 class motor: Energy-saving, durable and designed to operate in difficult industrial conditions.
- ES 4000 Standard Controller: Enables real-time monitoring of operating parameters, maintenance planning and optimization of operating costs.
- Cooling system: Multi-stage system with independent fans and air and oil coolers effectively dissipates heat, ensuring reliable operation even in intensive cycles.
Efficiency and energy saving
The APS 30BD IVR Dry compressor offers performance ranging from 770 to 4170 l/min at an operating pressure of up to 13 bar. The integrated refrigerant dryer and inverter technology allow for the delivery of the highest air quality with minimal energy consumption and optimization of operating costs.
Technical specifications:
- Operating pressure range: up to 13 bar
- Engine power: 30 HP / 22 kW
- Air flow: 770–4170 l/min
- Drive type: Direct 1:1
- Dehumidifier: Integrated refrigerant dryer
- Controller: ES 4000 Standard
- Noise level: 68 dB(A)
Versatility and efficiency
APS 30BD IVR Dry has been designed for versatile industrial applications. Thanks to its compact design, low noise level and built-in dehumidifier, the device ensures comfortable operation and the highest air quality. Durable components and advanced technologies guarantee long-term reliability.
Comprehensive support for the industry
Choosing the APS 30BD IVR Dry model is an investment in quality, economy and reliability. Thanks to an advanced control system, high efficiency and a built-in dryer, the device meets the requirements of even the most demanding users in the industrial industry.
