Screw Compressor APS 3 Combi Compact 400V 10 bar 3.0 hp/2.2 kW 261 l/min 90 l galvanized
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 360903-CG |
|---|---|
| EAN | 8712418409826 |
| Length (mm) | 750 |
| Width (mm) | 465 |
| Height (mm) | 1144 |
| Weight (kg) | 105,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Motor Type | AC |
| Drive | Direct driven 1:1 |
| Control panel | Login Zero |
| Air receiver | Yes |
| Capacity air receiver (l) | 90 |
| Galvanized tank | Yes |
| Maximum pressure (bar) | 10 |
|---|---|
| Free air delivery (l/min) | 261 |
| Free air delivery (m3/h) | 15.66 |
| Noise level dB(A) (0 m) | 65 |
| Noise level dB(A) (4 m) | 45 |
| Plug type | EU |
| Main air connection (") | 1/2 |
| Oilfree | No |
| Stages | 1 |
| Start | Direct |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| IP classification | IP54 |
| Variable speed (IVR) | No |
Description
APS 3 Combi Compact screw compressor 400V 10 bar 3 HP/2.2 kW 261 l/min 90 l (galvanized)
Mini screw compressors from the APS Combi Compact series are an absolute novelty in the Airpress offer. These compact oil injected coaxial compressors have been designed for industrial applications in limited capacity locations. Thanks to the unusual design, using a vertical oil tank and a separator, we managed to create the smallest, yet efficient and economical screw compressor that will fit on an area of less than 1 m².< /p>
Models in this series compress air to a maximum pressure of 10 bar and achieve a capacity of 261 l/min. Thanks to the optimal engine power and the use of a 1:1 direct drive, the device operates efficiently and reliably in continuous mode. The galvanized tank with a capacity of 90 liters is resistant to corrosion and works perfectly in difficult environmental conditions, such as high humidity or the presence of chemicals. The intuitive LOGIN ZERO controller ensures precise control of the device's operation.
The most important advantages of APS 3 Combi Compact:
- Compact design – Thanks to the vertical oil tank and separator, the device takes up less than 1 m², making it an ideal solution for tight workspaces.
- 1:1 direct drive – Connecting the FS14 screw block directly to the electric motor completely eliminates energy and pressure losses, ensuring higher efficiency and lower operating costs.
- Quiet operation – Noise level of 65 dB(A) makes the compressor one of the quietest in its class. A solid cover of the compression module, which serves a protective function, additionally silences the operation of the device.
- Galvanized tank – Corrosion resistant, ideal for use in environments with high humidity or exposure to chemicals.
- Mobility – Compact structure and small dimensions enable easy transport, which makes it a great solution for professionals providing mobile services in the field of spray thermal insulation, applying structural plasters and other construction, installation and service works.
Technical specifications:
- Operating pressure range: 10 bar
- Engine power: 3 HP / 2.2 kW
- Air flow: 261 l/min
- Noise level: 65 dB(A)
- Tank capacity: 90 l (galvanized)
- Coaxial design with oil injection
- Screw block: FS14
- Air connection: 1/2"
- Power supply: 400 V / 50 Hz / 3 phases
- Dimensions: 750 x 465 x 1144 mm
- Weight: 105 kg
Versatility and reliability
APS Combi Compact series compressors have been designed for continuous operation. Thanks to its compact design, efficiency and quiet operation, the device is perfect for a wide range of industrial applications, especially in difficult environmental conditions. Contact us to find out more!
