Screw Compressor APS 25 IVR X 10 bar 25 hp/18.5 kW 620-2550 l/min
SKU
369425-IVR
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 369425-IVR |
|---|---|
| EAN | 8712418366853 |
| Length (mm) | 1300 |
| Width (mm) | 880 |
| Height (mm) | 1185 |
| Weight (kg) | 430,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 25.0 HP / 18.5 kW |
| Motor efficiency class | IE3 |
| Motor Type | PM Synchroon Motor |
| Motor protection class | IP55 |
| Drive | Direct driven 1:1 |
| Control panel | MAM-6080 |
| Available languages | English, Dutch, Polish, German |
| Dryer | No |
| Air receiver | No |
| Capacity air receiver (l) | No |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
| Free air delivery at 8 bar (l/min) | 2550 |
| Free air delivery at 10 bar (l/min) | 2390 |
| Minimum free air delivery (l/min) | 620 |
| Minimum free air delivery (m3/h) | 37.2 |
|---|---|
| Maximum free air delivery (l/min) | 2550 |
| Maximum free air delivery (m3/h) | 153 |
| Noise level dB(A) (0 m) | 78 |
| Noise level dB(A) (4 m) | 58 |
| Cut-in pressure (bar) | 6 |
| Plug type | EU |
| Cooling air volume (m3/h) | 5400 |
| Main air connection (") | 1 1/4 |
| Minimum ambient temperature (°C) | 10 |
| Maximum ambient temperature (°C) | 45 |
| Oilfree | No |
| Oil capacity (l) | 15 |
| Stages | 1 |
| Start | Inverter |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | Yes |
| Minimum rpm 10 bar (rpm) | 820 |
| Maximum rpm 10 bar (rpm/Hz) | 2200 |
| Minimum energy consumption 10 bar (kW/m3/h) | 9.3 |
| Maximum energy consumption 10 bar (kW/m3/h) | 12.1 |
