Screw Compressor APS 20D Combi Dry 10 bar 20 hp/15 kW 1983 l/min 500 l
SKU
36214
- Direct delivery from our own stock.
- Have questions or need advice? Contact us!
- Thanks to our expertise, you can get the best product for your needs.
- Over 60 years of experience in compressed air technologies.
| SKU | 36214 |
|---|---|
| EAN | 8712418663662 |
| Weight (kg) | 410 kg |
| Length (mm) | 1,750 mm1.75 m |
| Width (mm) | 650 mm6.5 dm |
| Height (mm) | 1,750 mm1.75 m |
| Drive | V-belt driven |
| Start | Y-∆ |
| Motor Type | AC |
| Motor efficiency class | IE3 |
| Air-end | C55 |
| Stages | 1 |
| Control panel | ES 4000 S |
| Air receiver | Yes |
| Capacity air receiver (l) | 500 |
| Galvanized tank | No |
| Dryer | Yes |
| Dryer voltage (V) | 230 |
| Refrigerant | R134a |
|---|---|
| Workload (labor/rest %) | 100/0 |
| Minimum working pressure (bar) | 9.7 bar |
| Noise level dB(A) (0 m) | 65 |
| Noise level dB(A) (4 m) | 45 |
| Main air connection (") | 3/4 |
| Minimum ambient temperature (°C) | 1 |
| Maximum ambient temperature (°C) | 40 |
| Oilfree | No |
| Oil capacity (l) | 4 |
| Plug type | EU |
| Manufacturer | Airpress Polska Sp. z o.o. |
| Motor power (hp / kW) | 20.0 HP / 15.0 kW |
| Free air delivery (l/min)* | 1,983 L/m33.05 L/s |
| Free air delivery (m3/h)* | 118.98 m³/h1.983 m³/min |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Maximum pressure (bar) | 10 |
| Variable speed (IVR) | No |
* The output efficiency (l/min) is an estimated value, dependent on factors such as the intake air pressure, temperature, and humidity.
