Screw compressor APS 15 Basic Combi Dry 10 bar 15 hp/11 kW 1416 l/min 500 l
Only 4 left
SKU
364959
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- 50 years of experience in the field of air pressure.
Downloads
Download PDF
Details
| SKU | 364959 |
|---|---|
| EAN | 08712418347494 |
| Weight (kg) | 315,00 |
| Dimensions (mm) | 1935 x 620 x 1463 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 15.0 HP / 11.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | AC |
| Drive | V-belt driven |
| Control panel | ES 4000 BASIC |
| Dryer | 230 V / 50 Hz / 1 Ph |
| Air receiver | Yes |
| Capacity air receiver (l) | 500 |
| Galvanized tank | No |
| Maximum pressure (bar) | 10 |
|---|---|
| Free air delivery (l/min) | 1416 |
| Free air delivery (m3/h) | 84.96 |
| Noise level dB(A) (0 m) | 68 |
| Noise level dB(A) (4 m) | 48 |
| Plug type | EU |
| Refrigerant | R134a |
| Main air connection (") | 3/4 + 1/2 |
| Oilfree | No |
| Air-end | C55* |
| Stages | 1 |
| Start | Y-∆ |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | No |
Related product categories
Bundled Promotions
Description of screw compressor APS 15 Basic Combi Dry 10 bar 15 hp/11 kW 1416 l/min 500 l
Panel ES4000 BASIC
