Screw Compressor APS 15 Basic 10 bar 15 hp/11 kW 1416 l/min
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 364809 |
|---|---|
| EAN | 8712418347425 |
| Length (mm) | 810 |
| Width (mm) | 650 |
| Height (mm) | 975 |
| Weight (kg) | 185,00 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 15.0 HP / 11.0 kW |
| Motor efficiency class | IE3 |
| Motor Type | AC |
| Drive | V-belt driven |
| Control panel | ES 4000 BASIC |
| Dryer | No |
| Air receiver | No |
| Galvanized tank | No |
|---|---|
| Maximum pressure (bar) | 10 |
| Free air delivery (l/min) | 1416 |
| Free air delivery (m3/h) | 84.96 |
| Noise level dB(A) (0 m) | 68 |
| Noise level dB(A) (4 m) | 48 |
| Plug type | EU |
| Main air connection (") | 3/4 |
| Oilfree | No |
| Air-end | C55* |
| Stages | 1 |
| Start | Y-∆ |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| Variable speed (IVR) | No |
Recommended
Description
APS 15 Basic screw compressor 10 bar 15 HP/11 kW 1416 l/min
APS 15 Basic is an advanced screw compressor designed for demanding industrial applications. With an air flow of 1,416 l/min and a maximum working pressure of 10 bar, the device ensures efficiency, reliability and high air quality in everyday operations.
Advanced design of the APS Basic series
The APS 15 Basic compressor combines solid workmanship with modern technologies, ensuring optimal efficiency and durability. The high-quality screw module guarantees stable operating parameters, even in intense environments. The housing reducing noise to 68 dB(A) allows the device to operate comfortably near workstations, and the compact design facilitates its installation in limited spaces.
- Belt drive: Stable power transmission reduces energy consumption and increases component durability.
- IE3 motor: The energy-saving IE3 motor reduces energy consumption by up to 15%, lowering operating costs.
- Cooling system: Advanced air and oil coolers ensure optimal operating temperature, extending the life of the device.
- ES 4000 Basic controller: Intuitive control panel facilitates management of operating parameters and service planning.
Efficiency and air quality
APS 15 Basic offers an air flow of 1,416 l/min at an operating pressure of up to 10 bar. Thanks to high-quality compressed air, the compressor is ideal for powering advanced pneumatic tools and industrial devices that require stable operating parameters.
Technical specifications:
- Operating pressure range: up to 10 bar
- Engine power: 15 HP / 11 kW
- Air flow: 1416 l/min
- Noise level: 68 dB(A)
Versatility and efficiency
APS 15 Basic is an ideal solution for medium and large industrial plants that require stable operation of a high-performance device. The compressor is easy to install thanks to its compact design, and its energy-saving technologies minimize operating costs while ensuring maximum operating efficiency.
Investment in reliability
By choosing APS 15 Basic, you are investing in a device that combines durability, efficiency and ease of use. The use of durable materials and advanced technologies makes the compressor meet the needs of the most demanding users, offering long life and reliable operation in everyday operations.
