Screw Compressor APS 100 IVR X 10 bar 100 hp 4100-12400 l/min
SKU
3694100-IVR
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
SKU | 3694100-IVR |
---|---|
EAN | 8712418388299 |
Length (mm) | 1772 |
Width (mm) | 1300 |
Height (mm) | 1578 |
Weight (kg) | 1.250,00 |
Workload (labor/rest %) | 100/0 |
Motor power (hp / kW) | 100.0 HP / 75.0 kW |
Motor efficiency class | IE3 |
Motor Type | PM Synchroon Motor |
Motor protection class | IP55 |
Drive | Direct driven 1:1 |
Control panel | MAM-6080 |
Available languages | English, Dutch, Polish, German |
Dryer | No |
Air receiver | No |
Capacity air receiver (l) | No |
Galvanized tank | No |
Maximum pressure (bar) | 10 |
Free air delivery at 8 bar (l/min) | 12400 |
Free air delivery at 10 bar (l/min) | 10700 |
Minimum free air delivery (l/min) | 4100 |
Minimum free air delivery (m3/h) | 246 |
---|---|
Maximum free air delivery (l/min) | 12400 |
Maximum free air delivery (m3/h) | 744 |
Noise level dB(A) (0 m) | 85 |
Noise level dB(A) (4 m) | 65 |
Cut-in pressure (bar) | 6 |
Plug type | EU |
Cooling air volume (m3/h) | 13500 |
Main air connection (") | 2 |
Minimum ambient temperature (°C) | 10 |
Maximum ambient temperature (°C) | 45 |
Oilfree | No |
Oil capacity (l) | 50 |
Stages | 1 |
Start | Inverter |
Voltage (V) | 400 V / 50 Hz / 3 Ph |
Variable speed (IVR) | Yes |
Minimum rpm 10 bar (rpm) | 900 |
Maximum rpm 10 bar (rpm/Hz) | 2700 |
Minimum energy consumption 10 bar (kW/m3/h) | 7.8 |
Maximum energy consumption 10 bar (kW/m3/h) | 12.9 |
