Compressor LM 50-350 10 bar 3 hp/2.2 kW 245 l/min 50 l
- Airpress delivers from our own stock!
- Need advice? Contact us!
- Thanks to our knowledge, you have the best product.
- More than 60 years of experience in compressed air technologies.
Product details
| SKU | 36827 |
|---|---|
| EAN | 8712418343205 |
| Length (mm) | 760 |
| Width (mm) | 460 |
| Height (mm) | 680 |
| Weight (kg) | 50,00 |
| Workload (labor/rest %) | 40/60 |
| Start | Direct |
| Drive | Direct driven 1:1 |
| Cylinders | 2 |
| Voltage (V) | 230 V / 50 Hz / 1 Ph |
| Air receiver | Yes |
| Capacity air receiver (l) | 50 |
| Galvanized tank | No |
| Intake capacity (l/min) | 328 |
| Free air delivery (l/min) | 245 |
| Free air delivery (m3/h) | 14.7 |
|---|---|
| Cut-in pressure (bar) | 8 |
| Main air connection (") | 1/4 |
| Connection type | Universal |
| Number of reducable couplings air connections | 1 |
| Noise level dB(A) (0 m) | 96 |
| Noise level dB(A) (4 m) | 76 |
| Noise level dB(A) (7 m) | 71 |
| Sound volume reduction | No |
| Stages | 1 |
| Oilfree | No |
| Filter with reducer | Yes |
| Motor power (hp / kW) | 3.0 HP / 2.2 kW |
| Wheels | Yes |
| Intercooler | No |
| After cooler | No |
Recommended
Description
Two-piston compressor LM 50-350 – 10 bar, 3 HP, 245 l/min, 50 l
LM 50-350 compressor is an advanced model from the LM series, designed for mobility and demanding construction work. With a power of 3 HP (2.2 kW), a capacity of 245 l/min and a maximum pressure of 10 bar, this compressor is an excellent choice for intensive use in applications such as spray painting, assembly of wooden and steel structures and other tasks that require solid pressure and ease of transportation.
Equipped with a modern piston block with increased cylinder capacity, LM 50-350 offers high efficiency and durability. Oil lubrication of moving elements ensures smooth operation and extends the compressor's life, and the reduced speed (1450 rpm) increases the efficiency of the device, enabling it to operate in a cycle of 40% (work) to 60% (rest). This design makes LM 50-350 the perfect choice for professionals who require reliability and efficiency in intensive tasks.
The compressor is also equipped with thermal protection that protects the engine against overload and incorrect voltage, and the efficient cooler and copper supply pipes ensure the optimal temperature of the compressed air. The fan mounted on the front of the engine ensures constant air flow, effectively lowering the temperature, allowing for long-term use.
Large wheels and an ergonomic handle make the LM 50-350 easy to transport, so you can move it freely between workplaces. The standard drainage filter and pressure reducer ensure that the device is ready for operation immediately after purchase and the air quality is properly protected.
The most important features of the product:
- High pressure and efficiency: Maximum pressure of 10 bar and capacity of 245 l/min enable the implementation of advanced pneumatic tasks.
- Modern piston block: Increased cylinder capacity and oil lubrication ensure smooth, reliable operation.
- Optimum efficiency: Reduced speed (1450 rpm) and a duty cycle of 40% - 60% extend the life and increase the efficiency of the compressor.
- Cooling and protection: The radiator and copper supply pipes effectively reduce temperatures, and thermal protection protects the engine.
- Mobility: Large wheels and a handle make it easy to move the device to the construction site or between workstations.
- Filter and pressure reducer: Standard to ensure operational readiness and air quality.
The LM 50-350 compressor is a reliable, efficient device for professionals who need a mobile, durable compressor for intensive work. Thanks to its advanced design and solid functions, it will work well in any demanding work environment.
